| Materials of Construction |
| Filter Media: |
Pleated single layer of hydrophilic polyethersulfone |
| Support Material: |
Polypropylene |
| Structure Components: |
Polypropylene |
| Sealing Technology: |
Thermal bonding |
| |
| Dimensions |
| Nominal Length: |
10, 20, 30, and 40 inch (25.4, 50.8, 76.2, and 101.6 cm) |
| Diameter: |
69 mm |
| |
| Nominal Pore Sizes |
0.03, 0.1, 0.2, 0.45, 1.2 µm |
| |
| Typical Effective Filtration Area |
0.9 m²/10 inch |
| |
| Maximum Operating Temperature |
80°C at 30 psi (2.1 bar) |
| |
| Maximum Differential Pressure |
60 psi (4.1 bar) at ambient temperature |
| |
| Resistivity Recovery within 18 Mega-ohm |
≤120 L/10 inch length (at 1 L/min flow rate) |
| |
| Cleanliness |
<5 particles/mL (>0.2 μm particle after 5 minutes 18 mΩ water flush at 5 L/min flow rate) |
| |
| Retention Efficiency |
0.03 µm: >99.9% (retention of 0.055 µm PSL beads)
0.1 µm: >99.999% (retention of 0.198 µm PSL beads)
0.2 µm: >99.999% (retention of 0.460 µm PSL beads)
0.45 µm: >99.9% (retention of 0.830 µm PSL beads)
1.2 µm: >99.99% (retention of 2.0 µm PSL beads) |
