amcFluoropor

amcFluoropor PTFE membrane incorporates a polypropylene nonwoven web support for excellent durability and easer of handling.  Its high water intrusion pressure allows the membrane to repel high surface tension liquids while venting gases.  Membrane characteristics include excellent chemical resistance, high particle retention and steam sterilizability, making it a versatile material for clarification of solutions, gas filtration, and fluid sterilization. It is available in ranging from 260 mm width in roll form and various diameter discs in round shape.



Typical Applications

  • Supported membrane offers increased durability for hostile testing environments and sampling in aggressive environments.
  • Excellent chemical compatibility allows for harsh chemical and organic liquid filtration.
  • High hydrophobicilty makes it ideal for tank venting and other venting applications.

Specifications
Membrane Material: Supported PTFE membrane (Polypropylene nonwoven backing)
Nominal Pore Size: 1 μm
Typical Membrane Thickness: 0.15-0.32 mm
Typical Gurley Airflow (seconds/100 cc/20 oz/1.0 in²): 1 μm: ≤7
Minimum Bubble Point: 1 μm: 4 psi (0.28 bar)-IPA
Ordering Information
Product Number Description Packaging
FL100R01 1 μm, 100 m, linear length, ≤260 linear width 1/pkg
FL100DA3 1 μm, 13 mm, diameter 100/pkg
FL100DB3 1 μm, 25 mm, diameter 100/pkg
FL100DC3 1 μm, 47 mm, diameter 100/pkg
FL100DD3 1 μm, 90 mm, diameter 100/pkg
FL100DD2 1 μm, 90 mm, diameter 50/pkg
FL100DE1 1 μm, 142 mm, diameter 25/pkg

Not Available
