| Materials of Construction |
| Filter Media: |
amcMaxFlow PES: Pleated single layer of hydrophilic polyethersulfone
amcMaxFlow PES-A: Pleated single layer of proprietary asymmetrical hydrophilic polyethersulfone
amcMaxFlow PP: Pleated multiple layers of hydrophobic meltblown polypropylene
amcMaxFlow PTFE: Pleated single layer of unsupported hydrophobic polytetrafluoroethylene |
| Support Material: |
Polypropylene |
| Structure Components: |
Polypropylene |
| Sealing Technology: |
Thermal bonding |
| |
| Dimensions |
| Nominal Length: |
10 inch (27.0 cm) |
| Diameter: |
132 mm |
| |
| Nominal Pore Size |
amcMaxFlow PES: 0.03, 0.1, 0.2, 0.45, 1.2 μm
amcMaxFlow PES-A: 0.03, 0.1, 0.2, 0.45, 1.2 μm
amcMaxFlow PP: 0.2, 0.45, 1, 3, 5, 10, 30, 60 μm
amcMaxFlow PTFE: 0.05, 0.1, 0.2, 0.45, 1, 5 μm |
| Typical Effective Filtration Area |
amcMaxFlow PES: 3.2 m²/10 inch
amcMaxFlow PES-A: 3.2 m²/10 inch
amcMaxFlow PP: >1.8 m²/10 inch
amcMaxFlow PTFE: 3.3 m²/10 inch |
| |
| Maximum Operating Temperature |
80°C at 30 psi (2.1 bar) |
| |
| Maximum Differential Pressure |
60 psi (4.1 bar) at ambient temperature |
| |
| Resistivity Recovery within 18 Mega-ohm |
≤120 L/10 inch length (at 1 L/min flow rate) |
| |
| Cleanliness |
| amcMaxFlow PES: |
<5 particles/mL (>0.2 μm particle after 5 minutes 18 mΩ water flush at 5 L/min flow rate) |
| amcMaxFlow PES-A: |
<5 particles/mL (>0.2 μm particle after 5 minutes 18 mΩ water flush at 5 L/min flow rate) |
| amcMaxFlow PTFE: |
<10 particles/100 mL (>0.5 μm particle after 30 minutes 18 mΩ water flush at 5 L/min flow rate after alcohol wetting) |
| |
| Retention Efficiency |
| amcMaxFlow PES: |
0.03 μm: >99.9% (retention of 0.055 μm PSL beads)
0.1 μm: >99.999% (retention of 0.198 μm PSL beads)
0.2 μm: >99.999% (retention of 0.460 μm PSL beads)
0.45 μm: >99.9% (retention of 0.830 μm PSL beads)
1.2 μm: >99.99% (retention of 2.0 μm PSL beads) |
| amcMaxFlow PES-A: |
0.03 μm: >99.9% (retention of 0.055 μm PSL beads)
0.1 μm: >99.999% (retention of 0.198 μm PSL beads)
0.2 μm: >99.999% (retention of 0.460 μm PSL beads)
0.45 μm: >99.9% (retention of 0.830 μm PSL beads)
1.2 μm: >99.99% (retention of 2.0 μm PSL beads) |
| amcMaxFlow PP: |
0.2 μm: >99% (retention of 0.3 μm AC fine dust)
0.45 μm: >99% (retention of 0.6 μm AC fine dust)
1 μm: >99% (retention of 1.5 μm AC fine dust)
3 μm: >99% (retention of 5 μm AC fine dust)
5 μm: >99% (retention of 9 μm AC fine dust)
10 μm: >99% (retention of 15 μm AC fine dust)
30 μm: >99% (retention of 40 μm AC fine dust)
60 μm: >99% (retention of 70 μm AC fine dust) |
| Cartridge Configuration |
334/Flat |
